Water quality sensors, dual channel transmitter
Y551-B/C UV254 Self-cleaning COD Sensor.
| Product Introduction | Yosemitech Y551-B/C self-cleaning COD sensor based on the principle of ultraviolet absorption method,by measuring the absorption degree of these organic compounds to 254nm wavelength ultraviolet light,can accurately measure the content of dissolved organic pollutants in water.One turbidity detection light source is integrated in the interior,and the turbidity interference of the measured water is automatically compensated.With automatic cleaning brush device,even long-term monitoring stil as excellent stability. |
|---|---|
| Product Features | ◇ No reagents required,no pollution,more economical and environmentally friendly ◇ Can measure parameters such as COD,TOC,turbidity and temperature ◇ Automatically compensate for turbidity interference and have excellent test performance ◇ With automatic cleaning brush to prevent biological attachment and longer maintenance cycle ◇ Built-in calibration parameters for easy on-site use and secondary calibration. Link: Y551-B/C UV254 Self-cleaning COD Sensor |
| Certification | ISO 9001 CE UV |
| Details Images | Measurement principle Ultraviolet absorption method Ultraviolet absorption method, COD range: 0-500mg/L, 0-1500mg/L COD accuracy ±5% ±5% COD Resolution: 0.01mg/L Turbidity Accuracy 0-600mg/L ±5% ; Temperature range 0-50℃ ; IP rating: IP68 Sensor interface Supports RS-485,MODBUS protocol Supports RS-485,MODBUS protocol , Power consumption: 0.25W(non wiping),0.8W(wiping) Suggested power DC 12-24V,≥1A DC 12-24V,≥1A; Sensor size: φ50mm*179mm Cable length 10m(default),customizable 10m(default),customizable, Sensor housing material: 316L(Customizable titanium alloy) Hot Tags: y551-b/c uv254 self-cleaning cod sensor, China y551-b/c uv254 self-cleaning cod sensor manufacturers, suppliers, factory, Crane Scale Snsor, Antique solid Wood Bookshelf, Platform Indicator, LED Indicator For Load cell, Hall Effect Transducer SC145T SC145R, Closed Loop Hall Effect Sensor SC160T Link:Selection of high-precision water quality sensors |
| Customization options |
Customized logo (Min. order: 500 sets) Customized packaging (Min. order: 500 sets) Graphic customization (Min. order: 500 sets) |
| Place of Origin | shanghai China |
|---|---|
| Single gross weight | 2.25 |
| Single package size | 2.5X2.35X5.45 cm |
